The filling liquid level detector developed and produced by our company is a liquid level detection instrument that reaches advanced levels both domestically and internationally. Utilizing the principle that the intensity of radiation varies with the position of the detected material surface after the interaction between a low-energy photon source and the measured substance, it controls the detection of the volume of filling liquid material. Due to its non-contact measurement method, it fundamentally solves the problem that conventional weighing methods cannot measure the volume of filling liquid material on the production line. Therefore, it is widely used in online automatic control of liquid material production lines.
Functional Description
Application: Online liquid level detection for two-piece cans, three-piece cans, PET bottles, glass bottles, etc
1. Technical features
It can be directly detected after being powered on and started, without any need for preheating.
Non-contact detection, featuring fast detection speed and high accuracy.
It can automatically adapt to different production line speeds and dynamically achieve detection
The product features a stainless steel casing and a sealed design for the main unit, providing protection against fog and drips, and exhibiting strong environmental adaptability.
Automatically block the emission of high-frequency radiation during idle time
Implemented using hardware circuitry and an embedded operating system, it ensures stable operation over an extended period of time
Both sound and light will alarm simultaneously, and unqualified containers will be automatically eliminated.
Equipped with a 7-inch touchscreen display, it provides a simple and reliable human-machine interface, with flexible bottle type replacement
Large-screen Chinese display, LED-backlit LCD, with clear and bright characters, operated through human-machine dialogue.
It does not contain isotopic radioactive sources and adopts a soft-ray design, ensuring reliable radiation protection.
cost-effective
2. Main technical indicators
The linear speed of the conveyor belt in the production line is ≤1.8M/S. The high-speed detection rate for cans with a diameter of 50mm reaches up to 1200 cans per minute
Container diameter: 20MM~ 100MM.
(Different container materials, densities, and diameters require different device choices)
Dynamic container resolution: ±2MM.
(Foam and shaking can affect detection accuracy)
Static measurement accuracy of liquid level: ≤0.5MM (water)
8-hour static measurement stability: 0.15MM (water)
Unqualified container rejection rate: ≥99% (when the detection speed reaches 1200 units per minute)
Temperature error: within the range of 0℃ ~40℃,
The temperature error relative to the measured value at 20°C is ≤0.25MM
Job requirements: Requirements include the ability to detect the presence or absence of cans with a small time width of 10MS
Operating environment: Temperature 0℃~40℃, relative humidity not exceeding 95%,
Power supply: 220V ± 20V, 50HZ
Overall power consumption: ≤150W
Size: Length x Width x Height:
530MM x 150MM x 350MM
Scope of Application
Two-piece can, three-piece can, PET bottle, glass bottle, etc
